Anchor Chains · Short-Link Chain Cables
Short-link chain cables
We also offer short-link chain cables, with a wide range of chain sizes in stock in Rotterdam. They can be delivered as they are, tarred, or with a hot-dip galvanized finish. Whichever standard your windlass calls for, it’s held ready to cut and dispatch rather than made to order.
Dimensions are not binding and may vary.
DIN766 / DIN763 calibrated
NACM2010 stainless
Tarred or galvanized
Short-Link Chain
What short-link chain is
Short-link chain has no stud across the link, unlike stud-link chain. That makes it lighter and quieter over a windlass — the usual choice for yachts and smaller craft, though it’s also supplied for commercial and industrial use where a stud isn’t required. Because there’s no stud to hold the link’s shape under load, calibration matters even more here than on stud-link chain: the link has to be gauged accurately to run true over the gypsy without slipping or jamming.
DIN766
Calibrated chain, sized to run true over a matching gypsy — the most commonly requested standard we stock.
DIN763
Calibrated to a different profile than DIN766 — confirm which one matches your windlass before ordering.
NACM2010
A stainless steel standard, calibrated for windlass compatibility in corrosion-critical applications.
Finish options
As supplied (bare steel), tarred, or hot-dip galvanized — the finish affects both corrosion resistance and appearance on deck.
Certification is traced to the IACS unified requirements that classification societies apply to this chain cable. Tell us which standard and finish your project specifies and we’ll confirm what’s held in stock before you order.
Fittings Weight
Fittings weight
These figures are useful for working out total shipping weight and windlass loading before you order — the length column assumes a standard 27.5m shot, and the fitting weights are per individual piece, not per set.
| Nominal Diameter (mm) | Length, 27.5m (kg) | Kenter Joining Shackle (kg) | D-Type Anchor Shackle (kg) | Swivel Forerunner (kg) | GJW Super Swivel (kg) | Threelink Adapter (kg) |
|---|---|---|---|---|---|---|
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 13 |
| nominal diameter in mm | length (each 27,5 mtr) kg | kenter joining shackle (kg) | d' type anchor shackle (kg) | swivelforerunner (kg) | gjw super swivel (kg) | threelink adopter (kg) |
|---|---|---|---|---|---|---|
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
| 14 | 140 | 0.5 | 1.7 | 2.8 | 7 | 1.3 |
Request for quotation
Please fill out below form, so we can send you our best quote right away!
Questions
Answered straight, no sales pitch.
What standards do short-link chain cables come in?
DIN766, DIN763 and NACM2010, all held in stock at our Rotterdam yard in a wide range of sizes.
What's the difference between short-link and stud-link chain?
Short-link chain has no stud across the link, so it runs lighter and quieter over a windlass. Stud-link chain carries a stud to stop the link collapsing under load and is standard for commercial vessels. Neither is strictly “better” — the right one depends on your windlass, your vessel type, and whether the application calls for the extra strength a stud provides.
What finishes are available?
As supplied, tarred, or hot-dip galvanized.
Do you supply it in stainless steel?
Yes, to the NACM2010 standard, for corrosion-critical mooring and deck use.
Know Your Standard And Diameter?
Send us the spec.
Carbon Chains stocks this chain to DIN766, DIN763 and NACM2010, ready to ship from Rotterdam.
