Australian Short Link Chain | Marine Anchor Chain Solutions | Carbon
The Australian Short Link Chain is available in a variety of link dimensions. Suitable for a wide range of applications across the manufacturing, marine and agricultural industries, this versatile range of chain is proof tested to at least twice the maximum load recommended for normal use.
Material : Carbon Steel / Alloy Steel ( Mooring )
Surface : Polishing / Electro Galvanized / Hot Dip Galvanized
Packaging: Plywood drum or reel / Steel drum / Plastic drum or reel
Features
Chain Size | Working Load | Link Dimension | Length per 100kg | |||
D | L | B | SC & EG | HDG | ||
mm | tonnes | mm | mm | mm | meters | meters |
5 | 0.24 | 5 | 14.6 | 17.2 | 174 | 167 |
6 | 0.32 | 6.3 | 18.9 | 21.5 | 114 | 108 |
8 | 0.53 | 8 | 24 | 27.5 | 70.5 | 67 |
10 | 0.83 | 10 | 29.5 | 33.5 | 45.2 | 42.9 |
12 | 1.5 | 12.5 | 37.5 | 40.6 | 29.5 | 28 |
13 | 1.6 | 13 | 38.8 | 44.6 | 26.9 | 26.3 |
16 | 2.31 | 16 | 47 | 54 | 17.6 | 16.7 |
20 | 3.45 | 20 | 59.2 | 68.5 | 11.3 | 11.1 |
22 | 4.55 | 22 | 64.9 | 77 | 9.5 | 9.2 |
24 | 5.43 | 24 | 71 | 82.2 | 7.8 | 7.6 |
